TECHNICAL SPECIFICATIONS



PERFORMANCE

---

55,000 BTU main burner output

SIDE BURNER

---

10,000 BTU commercial-grade side burner

ROTISSERIE BURNER

---

15,000 BTU stainless steel rear rotisserie burner and premium rotisserie kit

TOTAL COOKING SPACE

---

875 sq. in. / 5,600 sq. cm. total cooking space including porcelain coated warming rack

PRIMARY COOKING SPACE

---

625 sq. in. / 4,000 sq. cm. primary cooking space

COOKING GRIDS

---

Professional cast stainless steel cooking grids

BURNERS

---

Five stainless steel Dual-Tube™ burners

FLAVOR SYSTEM

---

Stainless steel Flav-R-Wave™ cooking system

HEAT CONTROL

---

Linear-Flow™ valves with 180° sensi-touch™ control

IGNITION

---

Sure-lite™ electronic dual-electrode ignition system

THERMOMETER

---

Deluxe Accu-Temp™ thermometer

LID DESIGN

---

Roll-action lids with cast aluminium end caps

HANDLES

---

Stylish and durable stainless steel handles

DRIP TRAY

---

Slide-out grease tray system

CONSTRUCTION

---

Rust resistant zinc coated steel components

FINISH

---

Premium stainless steel finish

BUILT-IN LIGHTS

---

Built-in lights located in the cook box and on the control knobs

FUEL TYPE

---

Propane (LP) – designed for use with 20lb tank – not included.

- or -

Natural Gas (NG) – 10ft natural gas hose included.

ASSEMBLED GRILL DIMENSIONS

---

24.6 in. Height 27.0 in. Width 37.4 in. Length

GRILL WEIGHT

---

219.0 lbs (LP Model) 219.0 lbs (NG Model)

COOKING SURFACE

---

19.25 in. Width, 31.89 in. Length

WARRANTY

---

25 years on Stainless Steel / Porcelain Steel Lid Components
25 years on Cast Aluminum Cook box / Components
15 Years on Burners
15 Years on Remaining Parts & Paint
